█ Specifications
Model | JSA-8HSOTK36LA Series | Camera | Image Sensor | 1/2.8" Progressive CMOS Or 1/1.8" Progressive CMOS | Effective Pixels | 1920×108、2592×1520、3840×2160 Optional | Lens multiple | 46~100X Optics,16X Digital Optional | Wide dynamic | 120dB | Focal length | 260mm~610mm Optional | Minimum illumination | Color：0.1Lux；Black and white：0.01Lux | Automatic control | Auto white balance, focus, exposure, noise reduction, contrast enhancement | Signal to noise ratio | ≥50db | Function | Laser movement | 1000~2200m Synchronized laser/808nm[Optional 850、940 Or 1550±10nm] | Network protocol | Onvif,IPv4,HTTP,FTP,RTSP,DNS,NTP,RTP,TCP,UDP,IGMP,ARP, OptionalRTMP and GB/T28181 | Compressed standard | H.265/ H.264 | Multiple code streams | Full HD+ FULL D1 | Data storage | OptionalBuilt-in TF card local storage | Insight | Optional：Motion Detection, Intrusion Detection Or Perimeter Detection | Pan Angle | 0°~360° | Tilt Angle | -90°~ 40° | Pan Speed | 0.01°~40°/s | Tilt Speed | 0.01°~15°/s | Preset | 128 | Cruise | 1 | A/B line scan | Support | Memory as Power off | Support | Preset Accuracy | ±0.01° | Telephoto speed limit | Support | RS485 | Optional/ Support PELCO_D | BNC Output | BNC interface/optional | Network Interface | 10/100M*1 | Other | Temperature/ humidity | -40~ 70℃/ 0～90%(No condensation) | Power supply | AC24V/≤100W | Protection level | IP66 | Size | 489×327×160mm | Weight | ≈18kg |
█ Order model
| Ordering specification model | Camera parameters | Laser parameters | Remark | | JSA-8HSOTK36LA42X21K | 1920×1080/5~220mm/42X | 800~1000m | 2MP | | JSA-8HSOTK36LA46X21K | 1920×1080/5~260mm/46X | 1000~1200m | 2MP | | JSA-8HSOTK36LA46X41K | 2592×1520/5~260mm/46X | 4MP | | JSA-8HSOTK36LA46X4K1K | 3840×2160/5~260mm/46X | 8MP | | JSA-8HSOTK36LA55X21K | 1920×1080/6~330mm/55X | 1000~1200m | 2MP | | JSA-8HSOTK36LA55X41K | 2592×1520/6~330mm/55X | 4MP | | JSA-8HSOTK36LA55X4K1K | 3840×2160/6~330mm/55X | 8MP | | JSA-8HSOTK36LA60X22K | 1920×1080/6~390mm/60X | 2000~2200m | 2MP | | JSA-8HSOTK36LA55X22K | 1920×1080/7~530mm/55X | | JSA-8HSOTK36LA100X22K | 1920×1080/6~610mm/100X | | Customized models | Customization is made based on the standard price according to customer needs;
contact customization->aiptz@jsa-cctv.com, WeChat: A380487881 |
|
