Model

JSA-8HSOZ50LA Series

Camera

Image Sensor

1/2.8" Progressive CMOS Or 1/1.8" Progressive CMOS

Effective Pixels

1920×108、2592×1520、3840×2160Optional

Lens multiple

62~120X Optics,16X DigitalOptional

Wide dynamic

120dB

Focal length

610mm~1360mm Optional

Minimum illumination

Color：0.1Lux；Black and white：0.01Lux

Automatic control

Auto white balance, focus, exposure, noise reduction, contrast enhancement

Signal to noise ratio

≥50db

Laser movement

3000~5200m Synchronized laser/808nm[Optional 850、940 Or 1550±10nm]

Network protocol

Onvif,IPv4,HTTP,FTP,RTSP,DNS,NTP,RTP,TCP,UDP,IGMP,ARP, OptionalRTMP and GB/T28181

Compressed standard

H.265/ H.264

Multiple code streams

Full HD+ FULL D1

Data storage

OptionalBuilt-in TF card local storage

Insight

Optional：Motion Detection, Intrusion Detection Or Perimeter Detection

Pan Angle

0°~360°

Tilt Angle

-60°~ 40°

Pan Speed

0.01°~30°/s

Tilt Speed

0.01°~15°/s

Preset

128

Cruise

1

A/B line scan

Memory as Power off

Preset Accuracy

±0.01°

Telephoto speed limit

RS485

Optional/ Support PELCO_D

BNC Output

BNC interface/optional

Network Interface

10/100M*1

Temperature/ humidity

-35~ 65℃/ 0～90%(No condensation)

Power supply

AC24V/ ≤120W

Protection level

IP66

Size

588×366×525mm、588×366×600mm Or Customization

Weight

≈40kg
