Model

JSA-8HSOTAIR Series

Camera

Image Sensor

1/2.8" Progressive CMOS or 1/1.8" Progressive CMOS

Effective Pixels

1920×1080、2592×1520、3840×2160 Optional

Lens multiple

18~32X Optics,16X Digital Optional

Wide dynamic

120dB

Focal length

120mm~180mm

Minimum illumination

Color：0.1Lux；Black and white：0.01Lux

Automatic control

Auto white balance, focus, exposure, noise reduction, contrast enhancement

Signal to noise ratio

≥50db

LED

850nm LED light； Irradiation distance≤120m

Network protocol

Onvif,IPv4,HTTP,FTP,RTSP,DNS,NTP,RTP,TCP,UDP,IGMP,ARP, Optional RTMP and GB/T28181

Compressed standard

H.265/ H.264

Multiple code streams

Full HD+ FULL D1

Data storage

Optional Built-in TF card local storage

Insight

Optional：Motion detection, intrusion detection or perimeter detection

Pan Angle

0°~360°

Tilt Angle

-85°~ 90°

Pan Speed

0.01°~100°/s

Tilt Speed

0.01°~40°/s

Preset

200

Cruise

1

A/B line scan

Memory as Power off

Preset Accuracy

±0.01°

Telephoto speed limit

RS485

Optional output/ Support PELCO_D protocol

BNC Output

BNC*1 / Optional

Network Interface

10/100M*1

Temperature / humidity

-30~ 60℃/ 0～90%(No condensation)

Power supply

DC12V/5A, [Standby operation≤48W、peak≤60W]

Protection level

IP66

Size

380×221×251mm

Weight

≈8kg
