Network HD smart cloth control dome camera

[JSA-8HSOTC2IR Series]

█ Product pictures                                                     █ Product Size:(mm)

█ Functional characteristics

« Aluminum alloy structure design, waterproof grade IP66

« Antifogging: heating glass directly, removing fog in about 5 minutes

« Supporting ONVIF, GB28181 protocol, providing SDK for easy integration

« Selection of high quality infrared lamp, infrared irradiation distance greater than 80 meters

« Horizontal 360 degrees continuous rotation, vertical -15°～+90°degrees), automatic reversal

« Preset position: 255, maximum horizontal speed 150 degrees/S, maximum vertical speed 90 degrees/S

« Isolated power supply design, high stability, on-board power supply voltage input range: DC9V~DC36V

« Strong anti-electromagnetic interference ability, suitable for complex environment such as power industry

« The highest horizontal manual speed is 150 degrees/S, and the highest vertical manual speed is 90 degrees/S.

« Brake motors are used to support self-locking of the platform to enhance the wind resistance of the platform.

« The upper and lower structure design of camera and infrared cylinder makes it faster for customers to install their own cameras.

« Optional support for automatic tracking and intelligent analysis (face detection, area intrusion, tripping line detection hovering detection, retrograde detection, items left behind, items   removed, camera anomaly detection); only JSA-8HSOTC2594IRIVS model supports intelligent analysis.

█ Application

Ping'an City；Urban Management Law Enforcement；Outdoor Sports；Wedding Video Broadcasting；Police Vehicle Law Enforcement Vehicle；Location Control of Mobile Man-Car；Road Law Enforcement Vehicle；Distance Education/Medical Care；Community/Park Monitoring；Highway Mobile Law Enforcement。

█ Technical Parameters
