Model

JSA-8HSOTC18IR Series

Camera

Image Sensor

1/2.8" Progressive CMOS or 1/1.8" Progressive CMOS

Effective Pixels

1920×1080、2592×1520、3840×2160 Optional

Lens multiple

26~32X Optics,16X Digital Optional

Wide dynamic

120dB

Focal length

120mm~150mm

Minimum illumination

Color：0.1Lux；Black and white：0.01Lux

Automatic control

Auto white balance, focus, exposure, noise reduction, contrast enhancement

Signal to noise ratio

≥50db

LED fill light

850nm LED light； Irradiation distance≤100m

Network protocol

Onvif,IPv4,HTTP,FTP,RTSP,DNS,NTP,RTP,TCP,UDP,IGMP,ARP, Optional RTMP and GB/T28181

Compressed standard

H.265/ H.264

Multiple code streams

Full HD + FULL D1

Data storage

Optional Built-in TF card local storage

Insight

Optional：Motion detection, intrusion detection or perimeter detection

Pan Angle

0°~360°

Tilt Angle

-15°~ 90°

Pan Speed

0.01°~150°/s

Tilt Speed

0.01°~90°/s

Preset

200

Cruise

1

A/B line scan

Memory as Power off

Preset Accuracy

±0.01°

Telephoto speed limit

RS485

Optional output/ Support PELCO_D protocol

BNC Output

BNC*1 / Optional

Network Interface

10/100M*1

Temperature / humidity

-40 ~ 70℃ / 0～90%(No condensation)

Power supply

DC 9-36V (POE power supply Optional) /25W

Shock Absorbers

Protection level

IP66

Size

220×129 / Does not include shock absorbers

Weight

≈3kg
