4K Live camera rtmp decoder RTMP camera streaming live stream hdmi to rtmp encoder rtmp server

Detail

Parameters

Features

g Features

g Application

Industrial design appearance, suitable for finance, supermarkets, telecommunications, government, schools, airports, factories, hotels, museums and other indoor places, especially suitable for the intersection of light and shade, such as the bank counter, supermarket front door, hotel lobby and other indoor places requiring HD monitoring.

g Specification

Model	JSA-8LIVEHK800W4K
Optical	Sensor	1/1.8" CMOS
	Resolution	8MP
	Lens	3.6-11mm 3x optical AF lens
	MOD	10mm-1000mm(Wide-Tele)
	Aperture	F1.5-F2.7
	Illumination	0.01Lux @(F1.5,AGC ON) color, 0.005 Lux (F1.5,AGC ON) B/W
	Light	IR 90M (Optional: white light 50M)
	D/N Shift	ICR, Auto, Timing
	DNR	2D/3D DNR
Image Setting	Pixel	PAL: (3840 × 2160，1920 × 1080，1280 × 720)25fps
	Bite Rate	50Hz: PAL @ 25fps, 60Hz :NTCS @30fps
	Image Adjustment	Saturation, Brightness, Contrast, Sharpness, Hue Adjustment
	Image Setting	Privacy Mask, Anti-Flicker, Defog, Corridor Mode, Mirror, Rotation, BLC, HLC
	Character Overlay	Support channel name, date and time, multi-line character display, overlaid character size adjustment
	ROI	4 areas
Network	Intelligent Alarm	Motion Detection, Video tampering, Off-line, IP conflict, HDD Full
	Protocol	TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTMP，RTCP,PPPoE,NTP,UPnP,SMTP,SNMP, IPV6(Optional)
	Compatibility	ONVIF
	General	Three streams Heartbeat, Password
Compression	Standard	H.265 Main Profile H.264 Baseline/Main Profile/High Profile
Compression	Output Rate	32Kbps~10Mbps
Interface	Storage	Support
	Alarm Output	Support
	Alarm Input	Support
	Communication	RJ45*1, 10M/100M self-adaptive
	Audio Input	1ch
	Audio Output	Support
	Video Output	Support
Others	Working Temp.	-20℃ - +60℃, Humidity≤95% (non-condensing)
	Power Supply	DC12V
	Power Cons.	<7.5W
	Dimension	277121100mm
	Weight	1.65Kg
	Ingress Protection	IP67
